Monitor SDI Lilliput FS7 Full HD de 7 pulgadas con asistencia de cámara HDMI 4K
Monitor SDI Lilliput FS7 Full HD de 7 pulgadas con asistencia de cámara HDMI 4K
100 en existencias
DESCRIPCIÓN DEL PRODUCTO
Monitor SDI FS7 Full HD de 7 pulgadas con asistencia de cámara HDMI 4K
El monitor Lilliput FS7 es un monitor de pantalla ancha de 7" con entrada 4K HDMI 1.4 con bucle y bucle de entrada/salida SDI. Alojado en un marco de metal sólido y con una gran cantidad de funciones/opciones de encuadre adicionales, le brinda un control superior sobre su Flujo de trabajo ya sea en el campo o en el estudio.
ACCESORIOS
Mostrar | |
Tamaño | 7” |
Resolución | 1920 x 1200 |
Brillo | 500cd/m² |
relación de aspecto | 16:10 |
Contraste | 1000:1 |
Ángulo de visión | 170°/170°(H/V) |
Entrada de video | |
IDE | 1×3G |
hdmi | 1×HDMI 1.4 |
Salida de bucle de vídeo | |
IDE | 1×3G |
hdmi | 1×HDMI 1.4 |
Formatos de entrada/salida admitidos | |
IDE | 720p 50/60, 1080i 50/60, 1080pSF 24/25/30, 1080p 24/25/30/50/60 |
hdmi | 720p 50/60, 1080i 50/60, 1080p 24/25/30/50/60 , 2160p 24/25/30 |
Entrada/salida de audio (audio PCM de 48 kHz) | |
IDE | 12 canales 48 kHz 24 bits |
hdmi | 2 canales de 24 bits |
Gato de oreja | 3,5 mm - 2 canales 48 kHz 24 bits |
Altavoces incorporados | 1 |
Fuerza | |
Potencia operativa | ≤12W |
DC en | CC 7-24 V |
Baterías compatibles | Serie NP-F |
Voltaje de entrada (batería) | 7,2 V nominales |
Ambiente | |
Temperatura de funcionamiento | 0 ℃ ~ 50 ℃ |
Temperatura de almacenamiento | -20 ℃ ~ 60 ℃ |
Otro | |
Dimensión (LWD) | 182×124×22mm |
Peso | 405g |
Share
Very comparable to $1000 models at less of a price. BNC & HDMI in and out. You can loop either BNC or HDMI but you cant loop BNC to HDMI either way. But for the price it works great.
Good buy. Arrived on time.
Awesome price for a SDI monitor. Purchased to use as a camera viewfinder and this was perfect for that. Comes with hood and hot shoe adapter. I will buy another this year for sure.
I wanted to replace my Lilliput 663/O/P2 7" monitor with something better and not as heavy to put on the rear of my Sony FS7 (ironic that the camera and monitor models are FS7 huh?)I was a little bit apprehensive on buying this because it is very new and I couldn't find hardly any reviews on it. Let me say that initially I could not be any happier with this! Compared to the 663, it's way better all the way around. When I get my SDI cable in, it will be even better because all HDMI connections are inherent to a little bit of lag; but with SDI, it shouldn't be a problem.The resolution is sharp. Colors look really good. Brightness is good although I haven't tried it outside yet.The only thing is the screen itself is reflective and I'd prefer a matte screen vs glossy for that reason, but it really is a good purchase. I also wish it had a waveform and vectorscope like the 663 did, but the quality of the monitor is much much better so I'm happy.I'll update this later if I ever have any issues, but I can tell this is a really good buy.
